D-241

Description

  • Die-casting aluminium body, super white tempered glass.
  • Optics with PC lens with high visual comfortable and uniform lighting distribution, multiple light distribution options.
  • High quality LED chips, Driver with 0-10V/DALl/programmed be options, and with surge protection up to 20KV.
  • There are four installation methods: round rod, square rod, hoop and wall mounting, the Angle is adjustable, and the installation pipe diameter is 048 / 060mm / 089mm.
  • Surface anti-ultravilet pure polyester powder painting, Corrosion resistance can be more than 1000 hours.
  • No photo-biological risk, (no risk linked to infrared, blue light and UV radiation) in accordance with EN 62471 :2008.
  • Street lighting control used with smart control technology. It can be compatible with remote management system.
  • AllI external screw are in 304 stainless steel.
Lamp power: 40-100W
Output lumen:  6000-15000LM
Number of size:  3 installation methods and sizes
Color temperature option: 3000K/4000K
IP grade:  IP66
IK level: IK08
